| izes |
S (40cm), M (42.5cm), L (46cm) |
| Color |
Glitter dark blue metallic with sliver decals |
| Frame |
Hardtail BESV premium alloy frame with down tube for integrated Darfon battery, Shimano center-motor with protection cover, tapered 1 1/8″ – 1.5″ head tube, post disc mount, cold-forged dropout and replaceable hanger |
| Drive Unit |
Shimano EP-800 center-motor, 250W rated power, 85Nm of torque, 25km/h maximum assist |
| Battery |
Darfon integrated battery, 504Wh with 4A charger |
| Display |
Shimano EM-800 center mounted LCD display with Bluetooth™ connectivity |
| Fork |
RockShox Recon RL, air damping, remote lockout, tapered alloy steerer, travel 130mm |
| Crankset |
Shimano EM600, 34T chainring |
| Bottom Bracket |
Shimano, integrated in motor |
| Pedals |
Marwi SP-102, alloy body, ball bearings |
| Rear Derailleur |
Shimano XT 12 speed |
| Shifters |
Shimano XT 12 speed |
| Cassette |
Shimano Deore 12 speed, 10-51T |
| Kette |
KMC e12 EPT |
| Laufräder |
Shimano MT410 front and MT410-Boost rear hub, for Center Lock disc brakes, streight stainless steel spokes, 27.5″ multichamber alloy rims for disc brakes with 32H |
| Bereifung |
Maxxis High-Roller II, 27.5″Å~2.4″, EXO / TR, foldable |
| Bremsen |
Shimano MT420 / MT400, 4-piston front and 2-piston rear hydraulic disc, with 203mm front and 180mm rear rotors |
| Bremshebel |
Shimano MT401, 2 finger lever |
| Steuersatz |
FSA, 1 1/8″ – 1.5″ headset, ACB bearings |
| Lenker |
MTB riserr bar, 6061 alloy, double-butted, width: 760mm, 31.8mm clamp |
| Vorbau |
MTB alloy, length: 60mm, 31.8mm clamp |
| Griffe |
MTB gel grips with padding and BESV clamp |
| Sattel |
WTB Volt Sport |
| Sattelstütze |
Alloy micro-adjust, 31.6mm diameter, 0mm offset |
